ID LRM5400 / HF Long Range Reader Module
Key Features
- Write / Read ranges up to 2 m
- Adjustable transmitting power from 1 W – 8 W
- Easy network integration by IPv6 and IPv4 support and DHCP, DNS, NTP services
- Reader protection against fault conditions like antenna shortcut and antenna mismatching
- International radio and safety approval according to ETSI, FCC, IC, UL 62368 and EN 62368-1. More countries on request
| Dimensions (w x h x d) | 160 mm x 120 mm x 46 mm |
|---|---|
| Weight | approx. 0.6 kg |
| Power supply | 24 V ± 15 %; Noise Ripple: max. 150 mV |
| Operating frequency | 13.56 MHz |
| Transmitting power | 1 W – 8 W (250 mW steps, software configurable) |
| Modulation | 10 % – 30 % (software configurable) |
| Antenna connection | 4 x SMA Jack (50 Ω) |
| DC Supply at antenna connectors | 8 V (max. 150 mA) |
| Outputs | 2 Optocoupler (24 V, 30 mA) 2 Relays (2 x NO; 24 V, 1 A) |
| Inputs | 3 Optocoupler (5 V up to 24 V, 20 mA) |
| Interfaces | RS485, USB-Device, USB-Host, Ethernet (TCP/IP), (RS485 auxiliary devices) |
| Indicators, optical | 6 LEDs |
| Supported transponders | ISO 15693*, ISO 18000-3-A, ISO 18000-3M3 (Upgrade code required), NXP I-Code 1 |
| Protocol modes | ISO Host Mode, Buffered Read Mode, Notification Mode |
| Operation system | Embedded Linux |
| Other features | Anticollision function, Real time clock, RSSI data readout |
